Introducing the King Song S18, a wheel like never before. Move in ultimate Style and Comfort featuring an on board Adjustable Suspension System.
#scooterzmalaysia #kingsong #kingsongs18 #s18 #KSS18 #EUC #kingsongs18
Highlights: KS-S18 uses 12 big MOS tube TO-247, which can endure big current, has better heat dissipation, powerful in acceleration and slope climb.
Suspension Features: KS-S18 has a suspension spring length of 90mm compared to the Inmotion V11 at 70mm
One Word, Smooth!
Max Speed: 50km/h
Travel Range: 100km
Max Payload: 120KG
Motor Power: 2200W
Battery Size: 1100wh
Climbing Gradient: 40 Degrees
Charging Time: 6 Hours
Tyre Size: 18*3 Inch
Net Weight: 22KG
S18 comes with built-in trolley handle, which features anti-spinning function.
Optimized Weight for the KS-S18 at 22kg Nett: To ensure the most comfortable riding experience and in order to retain the slim design, Kingsong has compromised the battery capacity to 1,110wh. This allows some plus points towards portability factor which we believe most would appreciate.
The KS-S18 is available in two colours: Black and White
Look at the magic of the suspension. You might recognize those shoes. Machine testing by Kuji Rolls.
Last but not least, we would like to commend KingSong for putting this wonderful machine at a very sweet price point. Given the specs and the additional state of the art innovation, we think that definitely it is a bargain.
Pre Order today and be the first to own this beast.
We have started to collect pre order booking, secure a unit today with only MYR888 booking deposit.
The KS-S18 by King Song Estimated Release Date is expected in early June for Malaysia
For Pre Order:
Press the icon below for pre order enquiries :
-Opened by Appointment-
|Detailed Product Specification for KS-S18|
1. Sports Bike inspired design. Aerodynamics with air intake system. Aggressive curvature design
2. Variable Linkage dampening air suspension system using 200-57 suspension
a. X shaped suspension travel of 100mm
b. Suspension is interchangeable and allows for personal modification and custom ride style
c. Adjustable air suspension system from on to off. Off state still reacts to big bumps but will ride similar to a wheel without suspension.
d. Rotary switch for sensitivity adjustment
e. Different pressurization can be adjusted to according to rider weight
3. Padding designed in cooperation with Kujirolls
4. User Experience focused ergonomic design to connect wheel with rider
5. 12 MOS design connected to aluminum body frame for fast heat dissipation without the need of fan
6. Headlights are 2 times stronger to the 16X with 2*5w (high beam) and 2*4w (short beam) with automatic sensor to switch between modes
7. Ergonomic handle designed for pushing and lifting which can be hidden inside body frame when not in use.
8. First ever high performance wheel with limited wiring with all key components housed on PCB
9. Rear light dislaying battery level, braking and turning signals all within one singular unit.
10. 21700 Battery system for better; efficiency to space ratio
|Top Speed||Full speed unlocked after 10km.|
Max speed of 50km/h
(Factory alarm settings: Level 1- 18km
Sound alarm Level 2- 19km
Sound alarm Level 3- Sound alarm with tiltback)
|Mileage||1110Wh (around 100km)|
|Maximum Gradability||Around 40°|
Rated Power： DC 74V
Top Charging Voltage： DC 84V
Rated Capacity：1,110WhSmart BMS with balance and protect overshoot/ over discharge/ overcurrent/ short circuit/ overheating function, support monitoring the battery conditions via KingSong APP
|Charger Voltage||Input AC 80~240 V ，output DC 84V、2.5A|
|Charging Time||1110Wh: about 6h 2.5A|
|Color||White & black|
Dimension & Weight
|Dimension||557mm（H） x 530mm(L） X 200mm（W）|
|Suspension Specification||200-57 Air suspension|
|Suspension Distance||Using a variable lever the wheel has dampening travel distance of 100mm which is transferred to the rear spring|
suspension with a travel distance of 57mm.
|Pedal Altitude (from ground)||210-110mm|
|Tire Size||18inch Diameter 3.0"inch|
|Weight||1110wh around 22kg|
|EUC Port||Charging port; Switch port; Light sensor port; USB discharge port|
|Light UP Displays||Rear light housing displays battery level, braking and turning signals all in one unit|
|Lift Sensor||Lift sensor accurately senses and determines when wheel is lifted off the ground to stop tire rotation.|
|Roll Protection||45° left and right side. ( Motor stalls when over 45° )|
Place the machine vertically on the ground will restart automatically, no need to restart manually
|Speed Limit Protection||Beep alarm or voice alarm when exceed limit speed|
|Low Battery Protection||Low battery protection activated on 30% battery, speed will decreases linearly; when the battery is lower than 5%,|
voice alarm for charge, when battery at 0%, the front part of the pedal will rise to decelerate until full stop
|Higher Temperature Protection||When the motherboard reaches 80℃ it will cresult tiltback. When the motor reaches 120℃ it will result in tiltback.|
Alarm & Features
|Swith On/Off||Short press power key: turn on|
Long press: hear a click then turn off
|Battery Indicate||Led shows battery level when EUC power on at rest|
|Mainboard||The motherboard is designed with a 4 layer structure, allowing for better stability performance. 12 large individual|
TO-247 imported MOS to sufficiently support the 2200W motor. MOS is attached to the aluminate body frame of
the wheel for better heat dissipation.
|Bluetooth||Bluetooth 4.0. Allowing strong stable data transmission|
|USB Output||Quick charge 3.0|
|Front Light||2*5w light high beam with 2*4w short beam. Double the strength of the 16x, providing excellent illumination at|
|Temperature System||Temperature of the motherboard is continously closely monitorered to ensure rider safety|
|Handle||Aluminum constructed handle designed for ergonomic pushing of the wheel or lifting of the wheel|
|Motor||Higher power 2,200w motor that provides a maximum torque of 140N.m providing fast acceleration|
|Suspension System||Unique X shaped suspension system. Racing level suspension provides the ultimate support and shock absorption|
|Standard Accessories||1x Charger, 1x Manual, 1x Pump, 1x Warranty card, 1x QC certificate|
